Part Number : TA7317P
Function : PROTECTION CIRCUIT FOR OCL POWER AMPLIFIER AND SPEAKER / SIP 9PIN
Manufacturer : Toshiba
Pinout :
Description
* Over current detecting circuit
– Operation at the time of over load, such as a speaker terminal short.
* DC voltage detecting circuit
– Operation at the time when positive or negative DC voltage (+- 1.1V of detection level) has generated at output terminals.
* Muting circuit
– Transient noise protection when power is ON-OFF.
* Relay driver circuit (Drive current of 130mA at Max.)
* Operation by dual power supply.
