Part Number : K2983
Function : MOS FIELD EFFECT TRANSISTOR / SWITCHINGN-CHANNEL POWER MOS FET INDUSTRIAL USE
Manufacturer : NEC => Renesas Technology
Pinout :
Description
This product is N-Channel MOS Field Effect Transistor designed for high current switching application.
• Low on-resistance
RDS(on)1= 20 mΩ (MAX.) (VGS= 10 V, ID= 15 A)
RDS(on)2= 27 mΩ (MAX.) (VGS= 4.5 V, ID= 15 A)
• Low Ciss Ciss= 1200 pF TYP.
• Built-in gate protection diode
2SK2983 TO-220AB, 2SK2983-S TO-262, 2SK2983-ZJ TO-263
Datasheet PDF Download
Other datasheets in the file :
2SK2983,2SK2983-S,2SK2983-ZJ,2SK2983-ZJ-E1,2SK2983-ZJ-E2
