Part Number : 54F00LMQB
Function : Quad 2-Input NAND Gate
Manufacturer : National ->Texas Instruments
Pinout :
Description
* This device contains four independent gates, each of which performs the logic NAND function.
* Guaranteed 4000V minimum ESD protection
Acquired by Texas Instruments on September 23rd, 2011.
Datasheet PDF Download
