Part Number : 2N3714
Function : 100V NPN silicon power transistor
Manufacturer : Central Semiconductor
Pinout :
Description
The CENTRAL SEMICONDUCTOR 2N3713, 2N3714, 2N3715, and 2N3716 are silicon NPN power transistors manufactured by the epitaxial-base process, mounted in a hermetically sealed metal package designed for medium speed switching and amplifier applications.
Datasheet PDF Download
Other datasheets in the file :
2N3713,2N3714,2N3715,2N3716
