Part Number : W04M
Function : W005M Thru W10M / 1.5 Amp Single Phase Bridge Rectifier 50 to 1000 Volts
Manufacturer : Micro Commercial Components
Pinout :
Description
* Lead Free Finish/Rohs Compliant (Note1) (“P”Suffix designates Compliant. See ordering information)
* Low Profile Package
* Any Mounting Position
* Silver Plated Copper Leads
* Surge Overload Rating Of 50 Amps
* UL Recognized File # E165989
* Halogen free available upon request by adding suffix “-HF”
* Moisture Sensitivity Level 1
* Epoxy meets UL 94 V-0 flammability rating
Datasheet PDF Download
Other datasheets in the file :
W005M,W01M,W02M,W04G,W04M
