Part Number : TPS65170
Function : LCD Bias Supply / 28-Pin 5×5 mm QFN Package
Manufacturer : Texas Instruments
Pinout :
Description
The TPS65170 provides a simple and economic power supply solution for a wide variety of LCD bias applications.
In typical display panel applications, the boost converter generates the display panel’s source voltage Vs, the buck converter generates the system’s logic supply V LOGIC , and the two charge pump controllers regulate the external charge pumps generating the display transistors’ on and off supplies V GH and V GL.
Datasheet PDF Download
Other datasheets in the file :
TPS65170,TPS65170RHDR,TPS65170RHDT
