Part Number : TDA8560Q
Function : 2 x 40 W/2 Ohm stereo BTL car radio power amplifier with diagnostic facility
Manufacturer : Philips Electronics
Pinout :
Description
The TDA8560Q is an integrated class-B output amplifier in a 13-lead single-in-line (SIL) power package.
It contains 2×40 W/2Ωamplifiers in BTL configuration.
The device is primarily developed for car radio applications.
Datasheet PDF Download
Other datasheets in the file :
TDA8560Q,TDA8560Q/N1/S10,TDA8560Q/N2,TDA8560Q/N2/S10
