Part Number : TAS5558
Function : 8-Channel HD Compatible Audio Processor with ASRC and PWM Output / HTSSOP 56 Pin
Manufacturer : Texas Instruments
Pinout :
Description
The TAS5558 can drive eight channels of H-bridge power stages. Texas Instruments Power Stages are designed to work seamlessly with the TAS5558. The TAS5558 supports either the single-ended or bridge tied-load configuration. The TAS5558 also provides a high-performance, differential output to drive an external, differential-input, analog headphone amplifier.
Datasheet PDF Download
Other datasheets in the file :
TAS5558,TAS5558DCA,TAS5558DCAR
