Part Number : PZT2907A
Function : PNP Silicon Planar Epitaxial Transistor
Manufacturer : ON Semiconductor
Pinout :
Description
This PNP Silicon Epitaxial transistor is designed for use in linear and switching applications. The device is housed in the SOT-223 package which is designed for medium power surface mount
applications.
Features
• NPN Complement is PZT2222AT1
• The SOT-223 Package can be Soldered Using Wave or Reflow
• SOT-223 Package Ensures Level Mounting, Resulting in Improved Thermal Conduction, and Allows Visual Inspection of Soldered Joints. The Formed Leads Absorb Thermal Stress during Soldering Eliminating the Possibility of Damage to the Die
Datasheet PDF Download
Other datasheets in the file :
PZT2907A,PZT2907AT1,PZT2907AT1G,PZT2907AT3G,SPZT2907AT1G
