Part Number : MC33349N-4
Function : Lithium battery protection circuit for one cell battery packs
Manufacturer : Motorola => Freescale
Pinout :
Description
The MC33349 is a monolithic lithium battery protection circuit that is designed to enhance the useful operating life of a one cell rechargeable battery pack. Cell protection features consist of internally trimmed charge and discharge voltage limits, charge and discharge current limit detection, and a virtually zero current sleepmode state when the cell is discharged.
This protection circuit requires a minimum number of external components and is targeted for inclusion within the battery pack. This MC33349 is available in the SOT–23 6 lead surface mount package.
Datasheet PDF Download
Other datasheets in the file :
MC33349N,MC33349N-1,MC33349N-10,MC33349N-2,MC33349N-3
