Part Number : DG201B
Function : Improved quad CMOS analog switches, +/-22-V supply voltage rating, low on-resistance 45Ohm
Manufacturer : Vishay Semiconductors
Pinout :
Description
The DG201B, DG202B analog switches are highly improved versions of the industry-standard DG201A, DG202. These devices are fabricated in VishaySiliconix’ proprietary silicon gate CMOS process, resulting in lower on-resistance, lower leakage, higher speed, and lower power consumption.
These quad single-pole single-throw switches are designed for a wide variety of applications in telecommunications, instrumentation, process control, computer peripherals, etc.
An improved charge injection compensation design minimizes switching transients. The DG201B and DG202B can handle up to ± 22 V input signals, and have an improved continuous current rating of 30 mA. An epitaxial layer prevents latchup.
Datasheet PDF Download
Other datasheets in the file :
DG201B,DG201BAK,DG201BAK/883,DG201BDJ,DG201BDJ-E3
