Part Number : BAT46
Function : Small Signal Schottky Diodes / DO-35
Manufacturer : Vishay Semiconductors
Pinout :
Description
• For general purpose applications
• This diode features very low turn-on voltage and fast switching. This device is protected by a PN junction guard ring against excessive voltage, such as electrostatic discharges
• This diode is also available in the SOD-123 case with type designation BAT46W-V and in the MiniMELF case with type designations LL46
• AEC-Q101 qualified
Datasheet PDF Download
Other datasheets in the file :
BAT46,BAT46-TAP,BAT46-TR,BAT46W-V
