Part Number : 74LS95
Function :Synchronous 4-Bit Binary Counters
Manufacturer : Hitachi -> Renesas Electronics
Pinout :
Description
This 4-bit register features parallel and serial inputs, parallel outputs, mode control, and two clock inputs.
The register has three mode operation :
* Parallel (broadside) load
* Shift right (the direction Qa toward Qd)
* Shift left (the direction Qd toward Qa)
Datasheet PDF Download
Other datasheets in the file :
74LS95, HD74LS95, HD74LS95B, HD74LS95BD, HD74LS95BN
