Part Number : TPS2546
Function : USB Charging Port Controller and Power Switch with Load Detection / Available in 16-Pin QFN (3×3) Package
Manufacturer : Texas Instruments
Pinout :
Description
The TPS2546 is a USB charging port controller and power switch with an integrated USB 2.0 high-speed data line (D+/D–) switch. TPS2546 provides the electrical signatures on D+/D– to support charging schemes listed under device feature section.
TI tests charging of popular mobile phones, tablets and media devices with the TPS2546 to ensure compatibility with both BC1.2 compliant and non-BC1.2 compliant devices.
Datasheet PDF Download
Other datasheets in the file :
2546,TPS2546,TPS2546RTER,TPS2546RTET
