Part Number : TPS2105-EP
Function : TPS2105-EP V aux Power-Distribution Switch / SOT-23 (5Pin)
Manufacturer : Texas Instruments
Pinout :
Description
The TPS2105 is a dual-input, single-output power switch designed to provide uninterrupted output voltage when transitioning between two independent power supplies.
Both devices combine one N-channel (250 mΩ) and one P-channel (1.3-Ω) MOSFET with a single output.
The P-channel MOSFET (IN2) is used with auxiliary power supplies that deliver lower current for standby modes.
Datasheet PDF Download
Other datasheets in the file :
PD9M,TPS2105-EP,TPS2105MDBVREP,V62/14616-01XE
