Part Number : SN65HVD01
Function : SN65HVD01 3.3V RS-485 with Flexible I/O Supply and Selectable Speed
Manufacturer : Texas Instruments
Pinout :
Description
The SN65HVD01 is a low-power, 250 kbps or 20 Mbps data rate selectable RS-485 transceiver, utilizing a 1.65-V to 3.6-V supply for data and enable signals, and a 3.3 V ± 10% supply for bus signals. The device is designed for applications requiring synchronous (parallel transceiver) signal timing. On-chip transient suppression protects the device against destructive IEC 61000 ESD and EFT transients.
Datasheet PDF Download
Other datasheets in the file :
HVD01,SN65HVD01,SN65HVD01DRC,SN65HVD01DRCR,SN65HVD01DRCT
