Part Number : SD4841
Function : SD4840 Thru SD4844 / CURRENT MODE PWM CONTROLLER WITH BUILT-IN HIGH VOLTAGE MOSFET
Manufacturer : Silan Microelectronics
Pinout :
Description
SD4840/4841/4842/4843/4844 is a current mode PWM controller with low standby power and low start current for power switch. In standby mode, the circuit enters burst mode to reduce the standby power dissipation.
The switch frequency is 67KHz with ±2.5 KHz jitter frequency for low EMI.
Datasheet PDF Download
Other datasheets in the file :
SD4840,SD4840P67K65,SD4841,SD4841P67K65,SD4842
