LM339 PDF – Quad Differential Comparator

Posted on by 1pico

Part Number : LM339

Function : Quad Differential Comparator

Manufacturer : National ->Texas Instruments

Pinout :

LM339 datasheet

Description

The LM339 series consists of four independent precision voltage comparators with an offset voltage specification as low as 2 mV max for all four comparators. These were designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply
voltage. These comparators also have a unique characteristic in that the input common-mode voltage range includes ground, even though operated from a single power supply voltage.



Acquired by Texas Instruments on September 23rd, 2011.



LM339 Datasheet PDF Download

LM339 pdf

Other datasheets in the file : LM139, LM139AJ, LM139AJ/883, LM139AW/883

Datasheet PDF
