ADS8684 PDF – SAR ADC, 16 bits, 4 channels – TI

Posted on by 1pico

Part Number : ADS8684

Function :SAR ADC with 16 bits, 4 channels, 500 kSPS, and bipolar inputs off +5V supply

Manufacturer : Texas Instruments

Pinout :
ADS8684 datasheet

Description

The ADS8684 and ADS8688 are 4- and 8-channel, integrated data acquisition systems based on a 16-bit successive approximation (SAR) analog-to-digital converter (ADC), operating at a throughput of 500 kSPS. The devices feature integrated analog front-end circuitry for each input channel with overvoltage protection up to ±20 V, a 4- or 8-channel multiplexer with automatic and manual scanning modes, and an on-chip, 4.096-V reference with low temperature drift.

ADS8684 Block Diagram

ADS8684 Datasheet PDF Download

ADS8684 pdf

Other datasheets in the file : ADS8684IDBT, ADS8684IDBTR, ADS8688, ADS8688IDBT

Datasheet PDF

Related articles across the web

NE556N PDF – DUAL PRECISION TIMER – TI

Posted on by 1pico

Part Number : NE556N

Function :DUAL PRECISION TIMER

Manufacturer : Texas Instruments

Pinout :
NE556N datasheet

Description

These devices provide two independent timing circuits of the NA555, NE555, SA555, or SE555 type in each package. These circuits can be operated in the astable or the monostable mode with external resistor-capacitor (RC) timing control. The basic timing provided by the RC time constant can be controlled actively by modulating the bias of the control-voltage input.

FEATURES
• Two Precision Timing Circuits Per Package
• Astable or Monostable Operation
• TTL-Compatible Output Can Sink or Source up to 150 mA
• Active Pullup or Pulldown
• Designed to Be Interchangeable With Signetics NE556, SA556, and SE556

NE556N Datasheet PDF Download

NE556N pdf

Other datasheets in the file : JM38510/10902BCA, M38510/10902BCA, NA556, NA556D, NA556DG4



Datasheet PDF
