Part Number : MP2307
Function :3A, 23V, 340KHz Synchronous Rectified Step-Down Converter
Manufacturer : Monolithic Power Systems
Pinout :
Description
The MP2307 is a monolithic synchronous buck regulator. The device integrates 100mΩ MOSFETS that provide 3A of continuous load current over a wide operating input voltage of 4.75V to 23V.
Current mode control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents inrush current at turn-on and in shutdown mode, the supply current drops below 1µA.
This device, available in an 8-pin SOIC package, provides a very compact system solution with minimal reliance on external components.
Datasheet PDF Download
Other datasheets in the file :
MP2307, MP2307DN
