Part Number : MC1488D
Function : Quad Line Driver
Manufacturer : ON Semiconductor
Pinout :
Description
The MC1488 is a monolithic quad line driver designed to interface data terminal equipment with data communications equipment in conformance with the specifications of EIA Standard No. EIA−232D.
Features
• Current Limited Output
+-10 mA typical
• Power−Off Source Impedance
300 minimum
• Simple Slew Rate Control with External Capacitor
• Flexible Operating Supply Range
• Compatible with All ON Semiconductor DTL and TTL Logic Families
• Pb−Free Packages are Available
