Part Number : MAX5813
Function : Ultra-Small Quad-Channel 8-/10-/12-Bit Buffered Output DACs
Manufacturer : Maxim Integrated
Pinout :
Description
The MAX5813/MAX5814/MAX5815 4-channel, low-power, 8-/10-/12-bit, voltage-output digital-to-analog converters (DACs) include output buffers and an internal reference that is selectable to be 2.048V, 2.500V, or 4.096V.
The MAX5813/MAX5814/MAX5815 accept a wide supply voltage range of 2.7V to 5.5V with extremely low power (3mW) consumption to accommodate most low-voltage applications. A precision external reference input allows rail-to-rail operation and presents a 100kOhm(typ) load to an external reference.
Datasheet PDF Download
Other datasheets in the file :
MAX5813,MAX5813AUD+T,MAX5814,MAX5814AUD+T,MAX5815
