Part Number : MAX128BC
Function : Multirange, +5V, 12-bit DAS with 2-wire serial interface. INL(LSB) +1,-1
Manufacturer : Maxim Integrated
Pinout :
Description
The MAX127/MAX128 are multirange, 12-bit data acquisition systems (DAS) that require only a single +5V supply for operation, yet accept signals at their analog inputs that may span above the power-supply rail and below ground.
These systems provide eight analog input channels that are independently software programmable for a variety of ranges: ±10V, ±5V, 0 to +10V, 0 to +5V for the MAX127; and ±VREF, ±VREF/2, 0 to +VREF, 0 to +VREF/2 for the MAX128.
Datasheet PDF Download
Other datasheets in the file :
MAX127,MAX127ACAI,MAX127ACNG,MAX127AEAI,MAX127AENG
