Part Number : LX1684
Function :Voltage-Mode PWM Controller / DUAL OUTPUT PWM CONTROLLERS WITH 5-BIT DAC
Manufacturer : Microsemi Corporation
Pinout :
Description
The LX1684 is a monolithic, voltage mode pulse-width modulator controller. It is designed to implement a flexible, low cost buck (step-down) regulator supply with a minimal of external components.
Datasheet PDF Download
Other datasheets in the file :
LX1684, LX1684CD, LX1684CD-TR
