Part Number : LTC3245
Function : Wide Vin range, Low Noise, 250mA Buck-Boost Charge Pump
Manufacturer : Linear Technology
Pinout :
Description
The LTC3245 is a switched capacitor buck-boost DC/DC converter that produces a regulated output (3.3V, 5V or adjustable) from a 2.7V to 38V input.
The device uses switched capacitor fractional conversion to maintain regulation over a wide range of input voltage. Internal circuitry automatically selects the conversion ratio to optimize efficiency as input voltage and load conditions vary.
Datasheet PDF Download
Other datasheets in the file :
LTC3245,LTC3245EDE,LTC3245EMSE,LTC3245HMSE,LTC3245IDE
