Part Number : DRV8801A-Q1
Function : DRV8801A-Q1 DMOS Full-Bridge Motor Drivers / WQFN 16-pin package
Manufacturer : Texas Instruments
Pinout :
Description
The DRV8801A-Q1 device provides a versatile motor-driver solution with a full H-bridge driver.
The device can drive a brushed DC motor or one winding of a stepper motor, as well as other devices like solenoids. A simple PHASE and ENABLE interface allows easy interfacing to controller circuits.
Datasheet PDF Download
Other datasheets in the file :
DRV8801A-Q1,DRV8801AQRMJRQ1,DRV8801ARMJQ1
