GB042-10P-H10-E3000 – PCB to PCB Connector

Posted on by 1pico

Part Number : GB042-10P-H10-E3000

Function :0.4mm pitch PCB to PCB Connector

Manufacturer : www.lsmtron.co.kr

Pinout :
GB042-10P-H10-E3000 image

Description

1. GB042 series Connector is 0.4 mm pitch, low profile PCB to PCB SMT type connector.

2. Improved contact reliability with plug and receptacle contacting at 2 point simultaneously.

3. Stable unmating mechanism preventing receptacle contact from being deformed.

GB042-10P-H10-E3000 datasheet

GB042-10P-H10-E3000 Datasheet PDF Download

GB042-10P-H10-E3000 pdf

Other datasheets in the file : GB042-20P-H10-E3000, GB042-24P-H10-E3000

Datasheet PDF

Related articles across the web

PC817 PDF – DIP 4pin Photocoupler – Sharp

Posted on by

Part Number : PC817

Part Information : DIP 4pin General Purpose Photocoupler

Manufacturer : Sharp Electronics

Datasheet Information :

PC817X Seriescontains an IRED optically coupled to a phototransistor.
( PC817A, PC817B, PC817C, PC817D )
It is packaged in a 4pin DIP, available in wide-lead spacing option and SMT gullwing lead-form option.

Input-output isolation voltage(rms) is 5.0kV.

Collector-emitter voltage is 80V(*) and CTR is 50% to 600% at input current of 5mA.

PC817 Datasheet

[AdSense-A]

1. PC817 : 1-channel type

2. PC827 : 2-channel type
3. PC837 : 3-channel type
4. PC847 : 4-channel type

Appications
1. Computer terminals
2. System appliances, measuring instruments
3. Registers, copiers, automatic vending
4. Electric home appliances, such as fanmachines heaters, etc.
5. Signal transmission between circuits of different potentials and impedances.

PC817 Datasheet

PDF Download : [ Datasheet PDF ]
