Part Number : 2N2222A
Function : NPN switching transistors
Manufacturer : Philips Electronics
Pinout :
FEATURES
• High current (max. 800 mA)
• Low voltage (max. 40 V).
APPLICATIONS
• Linear amplification and switching.
DESCRIPTION
NPN switching transistor in a TO-18 metal package.
PNP complement: 2N2907A.
Other datasheets in the file : 2N2222
Part Number : LTV817C
Function : High Density Mounting Type Photocoupler
Manufacturer : LiteOn Technology
Pinout :
Applications
1. Computer terminals.
2. System appliances, measuring instruments.
3. Registers, copiers, automatic vending machines.
4. Electric home appliances such as fan heaters, etc.
5. Signal transmission between circuits of different potentials and impedances.
Features
Current transfer ratio
(CTR : MIN. 50% at IF=5mA, VCE=5V)
High input-output isolation voltage:
(VISO : 5,000Vrms)
Compact dual-in-line package
LTV-817 : 1-channel type
LTV-827 : 2-channel type
LTV-847 : 4-channel type
Options available :
-Leads with 0.4″(10.16mm)spacing (M Type)
-Leads bends for surface mounting(S Type)
-Tape and Reel of Type I for SMD(Add”-TA”Suffix)
-Tape and Reel of Type II for SMD(Add”-TA1″Suffix)
-VDE 0884 approvals (Add”-V”Suffix)
Other datasheets in the file : LTV-817, LTV-817M, LTV-817S, LTV-817S-TA
