Part Number : PC817
Part Information : DIP 4pin General Purpose Photocoupler
Manufacturer : Sharp Electronics
Datasheet Information :
PC817X Seriescontains an IRED optically coupled to a phototransistor.
( PC817A, PC817B, PC817C, PC817D )
It is packaged in a 4pin DIP, available in wide-lead spacing option and SMT gullwing lead-form option.
Input-output isolation voltage(rms) is 5.0kV.
Collector-emitter voltage is 80V(*) and CTR is 50% to 600% at input current of 5mA.
[AdSense-A]
1. PC817 : 1-channel type
2. PC827 : 2-channel type
3. PC837 : 3-channel type
4. PC847 : 4-channel type
Appications
1. Computer terminals
2. System appliances, measuring instruments
3. Registers, copiers, automatic vending
4. Electric home appliances, such as fanmachines heaters, etc.
5. Signal transmission between circuits of different potentials and impedances.
PC817 Datasheet
PDF Download : [ Datasheet PDF ]
