Part Number : C3987
Function : 2SC3987 / 2C3987 / NPN Planar Silicon Darlington Transistor / Driver Applications
Manufacturer : SANYO -> Panasonic
Pinout :
Description
* Suitable for use in switching of L load (motor drivers, printer hammer drivers, relay drivers).
* High DC current gain.
* Large current capacity and wide ASO.
* On-chip Zener diode of 60±10V between collector and base.
* Uniformity in collector-to-base breakdown voltage due to the adoption of an accurate impurity diffusion process.
* High inductive load handling capability.
* Micaless package facilitating mounting.
