Part Number : ADS7253
Function : ADSxx53 Dual, High-Speed, 16-, 14-, and 12-Bit, Simultaneous-Sampling, Analog-to-Digital Converters
Manufacturer : Texas Instruments
Pinout :
Description
The ADS8353, ADS7853, and ADS7253 belong to a family of pin-compatible, dual, high-speed, simultaneous-sampling, analog-to-digital converters (ADCs) that support single-ended and pseudo-differential analog inputs.
Small Footprint: WQFN-16 (3-mm × 3-mm) and TSSOP-16
Datasheet PDF Download
Other datasheets in the file :
7253,7853,8353,ADS7253,ADS7253IPW
